808nm 10W 9-Pin

808nm 10W 9-Pin

808nm 10W 9-Pin Window Package Laser Diode is multi-mode semiconductor laser diode, which can be equipped with the FAC lens to get the choice of either a square or linear beam, the 9-Pin window package laser diode is hermetic package, it is convenience for customers to store and operate. This 808nm 10W 9-Pin window package laser diode is part of our infrared laser product range, it is with high performance and long lifetime. Wavespectrum Laser offers various power options for the 808nm 9-Pin window package laser diodes to cater to different customer requirements.

Categories: ,

Inquiry

Wavespectrum Laser is a manufacturer of the quality and high performance diode laser products, we are committed to developing, producing and selling high performance laser products. The wavelength range is wide, product packaging variety, single mode fiber, multi-mode fiber and polarization maintaining fiber is available. We strictly control the product quality and have earned wide praise from customers all over the world with their outstanding performance.
Wavespectrum Laser offers a diverse range of laser diodes, including 808nm 10W 9-Pin window package laser diodes. Furthermore, we supply various power versions for the 808nm 9-Pin window package laser diodes. For the near-wavelength multi-mode laser diodes, we have options available at 755nm, 770nm, 780nm, 792nm, 830nm, 850nm, 880nm and 915nm meeting the diverse requirements of the customers.



Product Feature of 808nm 10W 9-Pin Window Package Laser Diode

Wavelength: 808nm
Output Power: 10W
Package: 9-Pin Window Package
FAC Lens Optional
FP Laser Products

Product Parameter of 808nm 10W 9-Pin Window Package Laser Diode



Specifications WSLD-808-010-H9-T-PD
Min Type Max
Center Wavelength@25℃ 808nm±10nm
Spectral Width(FWHM) ---- 3.0nm ----
OutputPower 9W 10W ----
Emitter Area 200x1μm
Beam Divergence (FWHM) ---- 35°┴ x 8°// ----
Temperature Coefficient of Wavelength ---- 0.3nm /℃ ----
Slope Efficiency ---- 1.2W/A ---
Threshold Current(Typ.) ---- 1.2A 2.0A
Operating Current(Typ.) ---- 9.5A 10.0A
Operating Voltage ---- 1.9V 2.3V
TEC Max.Voltage 9.8V
TEC Max.Current 6A
Thermistor 10K
Package Style 9-Pin Window
Recommended Operating Temperature 25℃



Product Drawing of 808nm 10W 9-Pin Window Package Laser Diode

9-Pin Window Package View

Product Application of 808nm 10W 9-Pin Window Package Laser Diode

Medical Treatment
Biological Detection
Sensing Application



808nm-10w-9-pin-window-package-laser-diode_390760.pdf

FAQs

For more questions visit our help center.

How do I choose the right model?

Select based on the wavelength, output power, and fiber connector (e.g., SMA905) you require. Please inform us if you need special modulation.

What are the advantages of your lasers?

Our lasers feature thermoelectric cooling and precise temperature control, ensuring more stable output, superior beam quality, and a longer lifespan for demanding applications.

Can the laser be controlled by an external signal?

Yes. Most models support TTL modulation, allowing you to quickly switch the laser or adjust its intensity via an external signal.

What about product quality and warranty?

We offer an 18-month warranty, and each unit undergoes rigorous aging tests to ensure reliability and a long service life.
