405nm 150mW

405nm 150mW Single Mode Laser Diode is TO18 package laser diode, it is with near TEM00 beam and built-in PD. This 405nm 150mW Single Mode Laser Diode with 3.8mm Package is violet laser product, it is with high performance and long lifetime. Wavespectrum Laser can also offer the different power version 405nm SM laser diodes to customer.

Categories: 405nm Single Mode Laser Diode, Single Mode Laser Diode

Inquiry

Wavespectrum Laser is a manufacturer of the quality and high performance diode laser products, we are committed to developing, producing and selling high performance laser products. The wavelength range is wide, product packaging variety, single mode fiber, multi-mode fiber and polarization maintaining fiber is available. We strictly control the product quality and have earned wide praise from customers all over the world with their outstanding performance.

Wavespectrum Laser can offer the 405nm 150mW Single Mode Laser Diode , and we can also supply the different power version 405nm SM laser diodes to customers. For the near wavelength laser diode, we can offer the 445nm, 480nm, 488nm, 495nm, 520nm, 525nm laser diode to customer.

Product Feature of 405nm 150mW Single Mode Laser Diode

Part number:WSLD-405-150m-1-PD(3.8mm)

Wavelength: 405nm

Output Power:TO18

TO18

Built-in PD

FP Laser Products

Product Parameter of 405nm 150mW Single Mode Laser Diode

Specifications	WSLD-405-150m-1
	Min	Type	Max
Center Wavelength@25℃	±5nm	405nm	±10nm
Spectral Width (FWHM)	2.0nm
Output Power	-	150mW	-
Emitter	Single
Recommended Operating Temperature	25℃
Beam Divergence (FWHM)	15°_┴ x5°_//	19.5°_┴ x 9°_//	24°_┴ x 12°_//
Slope Efficiency	-	1.6mW/mA	-
Threshold Current (Typ.)	-	40mA	75mA
Operating Current (Typ.)	-	135mA	170mA
Operating Voltage	-	5.0V	6.0V
Package Style	TO18(5.6mm)

Product Drawing of 405nm 150mW Single Mode Laser Diode

TO18 Package View

PIN Bottom View:

Electrically shorten LD module and store in non-extreme conditions.
Suggest using the constant current power supply.

Product Application of 405nm 150mW Single Mode Laser Diode

Medical Treatment

Biological Detection

Sensing Application

405nm-150mw-single-mode-laser-diode_964634.pdf
